Hexagonal Wire Netting Machine


They are classified five types according to the different opening: 1", 1 1/4", 11/2", 2", 3".
The machine can continuously work, below are the characteristics:

Smooth running, low noise, automatically stop and give an alarm when there's something wrong

Scope of weaving: 1.22m double width or 2.44m single width

Used clutch arrester, neatly handle

Concentrate lubricating system, simply operate

The motor's power: 2.2KW. Three-phase current





Type

Width

Distance of mesh hole

Wire diameter

Twist times

Weight

Power

mm

in

mm

SWG

YD20-12

1200-2000

12

3/8

0.40

27

3

2500

3

YD20-15

1200-2000

15

1/2

0.50

25

3

2500

3

YD20-18

1200-2000

18

5/8

0.55-0.70

24-22

3

2500

3

YD20-22

1200-2000

22

3/4

0.70-0.90

22-20

3-5

2500

3

YD20-27

1200-2000

27

1

0.70-0.90

22-20

3-5

2500

3

YD20-32

1200-2000

32

1-1/4

0.70-0.90

22-20

3-5

2500

3

YD20-44

1200-2000

44

1-1/2

0.90-1.2

20-18

3-5

2500

3

YD20-54

1200-2000

54

2

0.90-1.2

20-18

3-5

2500

3

YD20-76

1200-2000

76

3

1.2-1.6

18-16

3-5

4000

5.5

YD20-94

1200-2000

94

3-1/2

1.6-2.0

16-14

3-5

6000

7.5

YD20-94A

1200-2000

/

3-1/2

2.0-3.5

14-10

3-5

12000

15

YD20-110A

1200-2000

/

4

2.0-3.50

14-10

3-5

12000

15



Specification
(mm)

Max. Breadth
(mm)

Max. Wire Dia. (mm)

Weaving-vein Number

Speed of Main Axle

Power (kw)

Theoretical Manufacturing Speed

Exterior Size

Weight
(Ton)

Mesh Hole Count
/Minute

Meter
/Hour

Length
xWidth
xHeight

60x80

2300

2.7

3

25

11

25

165

5200x1400x2400

13

3300

3

3

25

15

25

165

6200x1400x2400

14

4300

3

3

25

22

25

165

7200x1400x2400

15

80x100

2300

3

3

25

11

25

195

5200x1400x2400

13

3300

3

3

25

15

25

195

6200x1400x2400

14

4300

3

3

25

22

25

195

7200x1400x2400

15

100x120

2300

3.2

3

25

11

25

225

5200x1400x2400

13

3300

3

3

25

15

25

225

6200x1400x2400

14

4300

3

3

25

22

25

225

7200x1400x2400

15
